Product Overview

BRI-Needel Roller Bearing

Jms Industrial Solution IKO Machined Type Needle Roller Bearings, including the BRI series, are known for their low sectional height and exceptionally large load ratings.

Request Quote

Jms Industrial Solution Machined Type Needle Roller Bearings, including the BRI series, are known for their low sectional height and exceptionally large load ratings. This design makes them highly space-efficient while maintaining performance.

Select Shaft dia. (mm) Identification number Mass (g) d (mm) D (mm) C (mm) Fw (mm) B (mm) Da Max. (mm) Yas max. (mm) Basic dynamic load rating C (N) Basic static load rating Co (N) Allowable rotational speed (min⁻¹) Assembled inner ring
9.525 BRI 61812 67.5 9.525 28.575 19.05 15.875 19.3 24.5 0.6 18900 19700 25000 LRB 61012
12.7 BRI 82012 79.5 12.7 31.75 19.05 19.05 19.3 26.5 1 21700 24400 20000 LRB 81212
12.7 BRI 82016 106 12.7 31.75 25.4 19.05 25.7 26.5 1 27600 33100 20000 LRB 81216
15.875 BRI 102212 91 15.875 34.925 19.05 22.225 19.3 29.7 1 23000 27100 18000 LRB 101412
15.875 BRI 102216 122 15.875 34.925 25.4 22.225 25.7 29.7 1.5 29100 36800 18000 LRB 101416
19.05 BRI 122412 102 19.05 38.1 19.05 25.4 19.3 32.9 1.5 25300 31900 16000 LRB 121612
19.05 BRI 122416 136 19.05 38.1 25.4 25.4 25.7 32.9 1.5 32100 43300 16000 LRB 121616
22.225 BRI 142616 152 22.225 41.275 19.05 28.575 25.7 36 1.5 34900 49900 14000 LRB 141816
22.225 BRI 142620 190 22.225 41.275 25.4 28.575 32 36 1.5 43200 65600 14000 LRB 141820
25.4 BRI 162816 166 25.4 44.45 25.4 31.75 25.7 39.2 1.5 36000 53500 13000 LRB 162016
25.4 BRI 162820 210 25.4 44.45 31.75 31.75 32 39.2 1.5 44600 70300 13000 LRB 162020
28.575 BRI 183016 182 28.575 47.625 25.4 34.925 25.7 42.4 1.5 38500 60000 11000 LRB 182216
28.575 BRI 183020 225 28.575 47.625 31.75 34.925 32 42.4 1.5 47700 78900 11000 LRB 182220
31.75 BRI 203316 220 31.75 52.388 25.4 38.1 25.7 45.1 1.5 43700 66900 11000 LRB 202416
31.75 BRI 203320 275 31.75 52.388 31.75 38.1 32 45.1 1.5 54200 88200 11000 LRB 202420
34.925 BRI 223516 235 34.925 55.562 25.4 41.275 25.7 48.3 1.5 44800 70900 9500 LRB 222616
34.925 BRI 223520 295 34.925 55.562 31.75 41.275 32 48.3 1.5 55600 93400 9500 LRB 222620
38.1 BRI 243716 250 38.1 58.738 25.4 44.45 32 51.5 1.5 47500 78900 9000 LRB 242816
38.1 BRI 243720 315 38.1 58.738 31.75 44.45 32 51.5 1.5 58900 103000 9000 LRB 242820
38.1 BRI 243820 350 38.1 60.325 31.75 44.45 32 53.1 1.5 58900 103000 9000 LRB 242820
38.1 BRI 243920 380 38.1 61.912 31.75 44.45 32 54.7 1.5 60100 108000 8500 LRB 243020
41.275 BRI 264116 325 41.275 65.088 25.4 47.625 25.7 57.8 1.5 51000 89400 8000 LRB 263216
41.275 BRI 264120 410 41.275 65.088 31.75 50.8 32 57.8 1.5 63200 118000 8000 LRB 263220
44.45 BRI 284824 735 44.45 76.2 38.1 57.15 38.35 69 1.5 90300 158000 7000 LRB 283624
44.45 BRI 284828 855 44.45 76.2 44.45 57.15 44.7 69 1.5 105000 191000 7000 LRB 283628
50.8 BRI 325224 810 50.8 82.55 38.1 63.5 38.35 74.3 2 94600 174000 6500 LRB 324024
50.8 BRI 325228 945 50.8 82.55 44.45 63.5 44.7 74.3 2 110000 210000 6500 LRB 324028
57.15 BRI 365624 885 57.15 88.9 38.1 69.85 38.35 80.7 2 98700 189000 5500 LRB 364424
57.15 BRI 365628 1040 57.15 88.9 44.45 69.85 44.7 80.7 2 114000 228000 5500 LRB 364428
63.5 BRI 406024 965 63.5 95.25 38.1 76.2 38.35 87 2 105000 211000 5500 LRB 404824
63.5 BRI 406028 1130 63.5 95.25 44.45 76.2 44.7 87 2 122000 255000 5500 LRB 404828
69.85 BRI 446828 1520 69.85 107.95 44.45 82.55 51.05 99.7 2 141000 259000 5000 LRB 445228
69.85 BRI 446832 1740 69.85 107.95 50.8 82.55 51.05 99.7 2 154000 290000 5000 LRB 445232
76.2 BRI 487232 1860 76.2 114.3 50.8 88.9 51.05 106.1 2 162000 316000 4500 LRB 485632
82.55 BRI 527632 1980 82.55 120.65 50.8 95.25 51.05 111.4 2.5 169000 342000 4000 LRB 526032
88.9 BRI 568032 2120 88.9 127 50.8 101.6 51.05 117.8 2.5 176000 368000 4000 LRB 566432
